FAG and INA Bearings: What Line Each Brand Covers and How to Read Their Designations

FAG and INA: Two Brands, One Quality Standard

When we talk about FAG and INA bearings, we mean two brands of the same industrial group, Germany's Schaeffler, with product lines that complement each other. FAG is historically known for its large-size bearings and heavy-duty applications, while INA is more associated with needle roller bearings and smaller-diameter components. Both share the same engineering and manufacturing standards. In Argentina they are also asked for as FAG or INA rulemanes: it is the same part, quoted with the same code.

In Argentine industry, FAG and INA bearings are a common reference in maintenance. They are found in gearboxes, electric motors, pumps, fans, machine tools, and earthmoving equipment. The key is to choose the correct type according to load, speed, and mounting conditions.

What Line Each Brand Covers

The FAG brand stands out for its wide range of bearings for radial and axial loads. Among the most requested subcategories are spherical roller bearings, cylindrical roller bearings, and tapered roller bearings. There are also deep groove ball bearings, angular contact bearings, and a line of special bearings that includes adapter and withdrawal sleeves.

INA, on the other hand, is strong in needle roller bearings, needle cages, axial needle roller bearings, and linear motion bearings. Although its catalog is different, they are often combined in the same equipment: an FAG bearing on the main shaft and an INA bearing on the secondary support or linear guide.

How to Read FAG Bearing Designations

FAG bearing designations follow a standardized system that indicates the type, dimensional series, and bore diameter. For example, in a deep groove ball bearing 6205, the 6 indicates the type, the 2 the diameter series (the light series), and the 05 the bore diameter in millimeters (05 × 5 = 25 mm). Suffixes such as 2RS (two rubber seals) or C3 (greater internal clearance) add information about sealing and internal clearance.

In spherical, cylindrical, or tapered roller bearings, prefixes and suffixes can be more specific. For example, cylindrical roller bearings of the SL series have designations like SL182226: SL18 22 indicates a single-row full-complement cylindrical roller bearing, that is, without a cage, and the remaining number defines the size. For metric tapered roller bearings the designation is numeric, such as 33115: the leading 3 indicates a tapered roller bearing, the next two digits the width and diameter series, and the last two the bore (15 × 5 = 75 mm).

FAG Spherical Roller Bearings: For Heavy Loads and Misalignment

FAG spherical roller bearings are the typical choice when there are high radial loads combined with some shaft misalignment. Their design with two rows of rollers and a spherical raceway in the outer ring allows them to absorb misalignment without losing load capacity. They are used in industrial fans, mills, conveyor belts, and mining equipment.

Within this subcategory, codes such as 20222-MB or 20240-MB belong to the 202 series, barrel roller bearings: the single-row variant of the spherical roller bearing, which accommodates misalignment but takes less axial load. The MB suffix indicates a solid brass cage, common in large-size bearings. There are also versions with tapered bore, identified with the letter K, which are mounted on adapter sleeves.

FAG Cylindrical and Tapered Roller Bearings: Applications and Designations

FAG cylindrical roller bearings support high radial loads and allow high speeds. They are separable, which facilitates separate mounting and dismounting of the rings. The most common series are N, NU, NJ, and NUP, depending on the arrangement of the flanges. Those of the SL series, such as SL182226 or SL183018, are full-complement, without a cage: they carry as many rollers as possible, take very high radial loads and run at lower speeds than caged designs.

FAG tapered roller bearings, on the other hand, support combined radial and axial loads. They are mounted in pairs, face-to-face or back-to-back, to absorb loads in both directions. Codes such as 33115 or 32326 correspond to metric series: the 3 indicates the type, the next two digits the width and diameter series (31 and 23), and the last two the bore diameter (75 and 130 mm). They are common in vehicle wheels, machine tool heads, and gearboxes.

FAG Adapter and Withdrawal Sleeves

Adapter and withdrawal sleeves are indispensable accessories for mounting bearings with tapered bore on cylindrical shafts. They allow precise fitting and facilitate dismounting without damaging the bearing or the shaft. FAG offers a wide range of sleeves, identified with the H, AH, and AOH series.

For example, withdrawal sleeves AH211 or AH308 are used to extract bearings with tapered bore. The number is not the shaft diameter: it indicates the series and bore of the bearing the sleeve is made for (in the AH308, 08 = a bearing with a 40 mm bore, on a smaller shaft). These accessories are ordered together with the corresponding bearing, as they must be compatible in dimensions and taper.

Order Your FAG or INA Bearing with the Correct Code

To get a quote for an FAG or INA bearing, the most practical thing is to have at hand the complete code that appears on the part or on the equipment plate. If you don't have it, you can send us a photo of the bearing or the main dimensions: inner diameter, outer diameter, and width. With that data we will indicate the correct alternative.

At MR Accesorios Industriales, from Buenos Aires, Argentina, we distribute FAG and INA bearings for all types of industries. We work with the most demanded subcategories: spherical, cylindrical, tapered roller bearings, deep groove ball bearings, angular contact, and special bearings. Write to us via WhatsApp or email and we will quote you promptly.

Frequently asked questions

What is the difference between FAG and INA?

FAG specializes in ball and roller bearings for heavy and industrial applications, while INA is a leader in needle roller bearings and components for linear motion. Both brands belong to the same group and share quality standards.

How do I identify the type of FAG bearing by its code?

The code follows a standard: the first digit indicates the type (for example, 6 for deep groove ball bearings, 2 for spherical roller bearings, 3 for tapered roller bearings). The following numbers define the series and bore diameter. Suffixes such as 2RS or C3 indicate sealing or internal clearance.

What does the MB suffix mean in an FAG bearing?

The MB suffix indicates that the bearing has a solid brass cage. It is common in large-size roller bearings, such as the 202 series barrel roller bearings or the 248 series spherical roller bearings.

What are FAG adapter sleeves used for?

Adapter sleeves are used to mount bearings with tapered bore on cylindrical shafts. They allow precise fitting and facilitate mounting and dismounting. They are identified with series such as H, AH, or AOH.

How do I request a quote for FAG or INA bearings?

You can write to us via WhatsApp or email with the bearing code, dimensions, or a photo of the part. We will quote you promptly from Buenos Aires, Argentina.

Are FAG and INA the same company?

They are two brands of the same group, Germany's Schaeffler. That is why they appear together as "INA FAG" on catalogs and boxes, and they are often combined in the same machine. At MR Accesorios Industriales we sell and distribute genuine FAG and INA bearings: request a quote by code, by size, or with a photo of the part.
